Product Description
Introducing the X-Series XP-4AD-FB-W — a powerful 4MP WiFi IP camera featuring ONVIF support, Active Deterrence, and full compatibility with X-Series NVR/XVR systems.
With a 4-megapixel high-definition resolution, this camera captures crystal-clear footage day and night, allowing you to monitor your property 24/7. Advanced full-color night vision technology ensures vivid detail even in complete darkness, delivering exceptional clarity and peace of mind.
The XP-4AD-FB-W also features Active Deterrence — a proactive security technology designed to stop threats before they escalate. Built-in red/blue warning lights and an integrated siren can be configured to activate automatically when motion is detected, discouraging intruders from approaching your property.
Intelligent SMD (Smart Motion Detection) technology distinguishes between humans, vehicles, and animals, dramatically reducing false alerts. Additional AI analytics include Line Crossing, Loitering Detection, and Perimeter Protection for advanced security monitoring.
Easy to install and configure using the mobile app, this 2.4GHz WiFi camera is suitable for both indoor and outdoor use. Its rugged all-weather housing is built to withstand harsh environmental conditions.
Features
- 1/3" 4.0 Megapixel Progressive Scan CMOS Sensor
- 4MP (2560 × 1440) @ 25 FPS Encoding
- H.265 / H.264 Video Compression
- 2.4GHz WiFi Supported
- Smart Motion Detection (Human / Vehicle / Animal)
- Active Deterrence (Red/Blue Warning Lights, Siren, Custom Voice)
- Full-Color Night Vision / IR Selectable
- Audio Support with Built-in Microphone and Speaker
- 2.8mm Fixed Lens
- Dual-Stream Recording
- DDNS Support
- MicroSD Slot (up to 512GB)
- ONVIF Compatible
- DC 12V / PoE Power
- IP66 Weatherproof Rating
- NDAA and FCC Compliant
Specifications
| Camera | |
|---|---|
| Imaging Device | 1/3" 4.0MP Progressive Scan CMOS |
| Effective Pixels | 4MP (2560 × 1440) |
| Minimum Illumination | Color: 0.002 Lux @ F1.0 (AGC ON) / B&W: 0 Lux (IR ON) |
| Lens | Fixed (M12) / 2.8mm |
| Field of View | H: 95° / V: 51° / D: 112° |
| IR Distance | 25m |
| Warm Light Distance | 20m |
| Wide Dynamic Range | DWDR |
| Image & Video | |
| Video Compression | H.265 / H.264 |
| Resolution |
Main Stream: 4MP (2560 × 1440) @ 25fps Sub Stream: 720p (1280 × 720) @ 25fps |
| Bitrate Control | CBR / VBR |
| Interfaces | |
| Network | 2.4GHz WiFi |
| Audio | Built-in Microphone & Speaker |
| Local Storage | MicroSD (up to 512GB) |
| AI & Active Deterrence | |
| Smart Motion Detection | Human / Vehicle / Animal |
| Additional AI | Line Crossing, Loitering, Region Enter/Exit |
| Active Deterrence | Siren, Red/Blue Strobe, Custom Voice |
| General | |
| Power Supply | DC 12V |
| Power Consumption | Max 6.2W |
| Ingress Protection | IP66 |
| Operating Temperature | -20°C to +55°C (-4°F to 131°F) |
| Compliance | NDAA & FCC Compliant |
