Product Description
The XP-4MP-4G X-Series 4G AI Camera delivers powerful remote surveillance anywhere cellular coverage is available. Featuring 4MP video, 2.8-12mm motorized zoom lens, a Starlight sensor for ultra-low-light color imaging, intelligent people, vehicle and license plate detection, active deterrence siren/light, built-in 4G LTE and Wi-Fi hotspot capability, and support for up to 1TB MicroSD storage, it’s ideal for locations where traditional wired internet isn’t practical. Triple-stream video, two-way audio, ONVIF compatibility, and an IP67 weatherproof housing make it a flexible, professional-grade solution for standalone or multi-camera security installations. The camera is also a great fit for off-grid applications requiring 24x7 recording, all-weather protection, and reduces complexity by combining 4G connectivity and a high performance camera into one single package.
- 1/1.8" 4.0 Megapixel, Progressive Scan, CMOS Sensor
- 4MP (2688 x 1520) @30FPS Encoding
- 4G LTE Micro SIM Support
- 2.4Ghz WiFi (Client and Hotspot Functions)
- H.265+/H.265/H.264+/H.264 Video Compression
- Advanced AI (Person/Vehicle, Perimeter, Line Crossing, Cross Counting, Stationary Object, Heat Map, Crowd Density, Queue Length, Rare Sound, License Plate Recognition, Region Entrance/Exit)
- Active Deterrence (White Strobe/Warning Lights, Siren, Custom Voice)
- Full Color Night Vision / IR Selectable
- True 120db Wide Dynamic Range
- Audio, Built-in Mic and Speaker
- 2.8-12mm Motorized Zoom Lens
- Triple-Stream Recording
- NAS and FTP Network Storage
- DDNS
- Micro SD Slot (up to 1TB)
- ONVIF Compatible
- DC12V
- IP67 Waterproof Rating
- NDAA and FCC Compliant
Specifications
| Camera | |
|---|---|
| Imaging Device | 1/1.8" Progressive Scan CMOS |
| Effective Pixels | 4MP (2688 × 1520) |
| Minimum Illumination | Color: 0.0005 Lux @ F1.0 (AGC ON) / B&W: 0 Lux (IR ON) |
| Lens | 2.8–12mm Motorized Varifocal |
| Maximum Aperture | F1.2 |
| Field of View | H: 110°–40° / V: 57°–22° / D: 137°–46° |
| Minimum Object Distance | Wide: 1.75m / Tele: 5.21m |
| IR LEDs | 4 |
| Warm Light LEDs | 4 |
| IR Distance | Up to 30m Full Power / Up to 20m Low Power |
| Warm Light Distance | Up to 25m |
| Supplemental Lighting | Warm Light / Infrared, Switchable |
| Wide Dynamic Range | WDR |
| Digital Noise Reduction | 3D DNR |
| Image Modes | Full Color / Day & Night / Smart Illumination |
| White Balance | Auto / Manual |
| Electronic Shutter | 1/5s to 1/20000s |
| Image & Video | |
| Video Compression | H.265 / H.264 / H.265+ / H.264+ |
| Maximum Resolution | 4MP (2688 × 1520) @ 30fps |
| Triple Stream |
Main Stream: 4MP (2688 × 1520), 3MP (2304 × 1296), 1080p (1920 × 1080), 720p (1280 × 720) Sub Stream: 720p (1280 × 720), VGA (640 × 480), QVGA (320 × 240) Mobile Stream: VGA (640 × 480), QVGA (320 × 240) |
| Video Bitrate | 256Kbps – 8Mbps |
| Bitrate Control | CBR / VBR |
| Network & Connectivity | |
| 4G Cellular | LTE-TDD / LTE-FDD / WCDMA / GSM |
| SIM Card | Micro SIM |
| Wi-Fi | IEEE 802.11b/g/n, 2.4GHz / Built-in Wi-Fi Hotspot |
| Ethernet | 1 × RJ45 10/100BASE-T |
| IP | IPv4 / IPv6 |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, CIFS, SMB, NFS |
| ONVIF | Profiles S / G / T |
| Security | IP Address Filtering / Password Authentication |
| 4G Frequency Bands | |
| LTE-TDD | Bands 38 / 39 / 40 / 41 |
| LTE-FDD | Bands 1 / 2 / 3 / 4 / 5 / 7 / 8 / 12 / 13 / 18 / 19 / 20 / 25 / 26 / 28 |
| WCDMA | Bands 1 / 2 / 4 / 5 / 6 / 8 / 19 |
| GSM | GSM850 / EGSM900 / DCS1800 / PCS1900 |
| Audio, Alarm & Storage | |
| Audio | Built-in Microphone & Speaker / 1 Audio Input / 1 Audio Output |
| Alarm I/O | 1 Alarm Input / 1 Alarm Output |
| Custom Voice | Yes |
| Local Storage | MicroSD up to 1TB |
| Hardware Reset | Yes |
| AI & Smart Analytics | |
| People & Vehicle Detection | Supported |
| License Plate Recognition | Supported |
| Perimeter Analytics | Line Crossing, Intrusion, Region Entrance, Region Exit |
| Object Detection | Supported |
| People Counting | Crossing Counting, Crowd Density, Queue Length |
| Additional Analytics | Heat Map, Rare Sound Detection |
| Motion Detection | On / Off, 8 Sensitivity Levels |
| Environmental | |
| Ingress Protection | IP67 |
| Wind Resistance | Level 12 |
| Operating Temperature | -20°C to +60°C (-4°F to 140°F) |
| Operating Humidity | 95% or Less, Non-Condensing |
| Housing Material | Metal |
| Physical Specifications | |
| Overall Dimensions | 353.17mm × Ø134.34mm (13.9" × Ø5.3") |
| Mounting Base to Camera Front | 332.3mm (13.1") |
| Camera Body Length | 165mm (6.5") |
| Weight | 5 lbs (2.27 kg) |
| Power | |
| Power Connection | 4-Pin Waterproof Connector / 12VDC Connector |
| Maximum Power Consumption | 11W (Full Power Mode, IR On), 3W Avg |
Product Videos
Custom Field
Active Deterrence Yes
FPS 30
Night Vision Ultra Low Light Full Color
Advanced AI Yes
Lens Motorized Varifocal
WDR True 120dB
Resolution 4MP
Style Bullet
Facial Recognition No
Audio Yes
LPR Yes
