Product Description
Introducing the X-Series XP-PTZ4.The X-Series advanced 4x PTZ IP camera with active deterrence, advanced AI, and infrared night vision, is designed to provide unparalleled security and surveillance for both residential and commercial properties.
Featuring a 4x optical zoom lens, 4K ultra high definition sensor, and pan-tilt-zoom functionality, this camera allows you to remotely control and view your property in high-definition from anywhere, at any time. With active deterrence technology, it also includes built-in alarms and strobe lights to actively deter potential intruders and safeguard your property. View the Videos tab above for some demonstrations.
Our mini PTZ Camera also comes equipped with AI technology, which takes your surveillance to the next level. With AI-powered features such as facial recognition and object detection, you can customize your camera's settings to suit your specific needs. The camera can even send real-time alerts to your phone or computer when it detects any suspicious activity, so you can act quickly and prevent any potential threats.
This camera also features auto-tracking. Automatically tracking pedestrians or vehicles as they move throughout the scene.
Additionally, the camera’s infrared night vision technology allows for clear and detailed monitoring, even in low-light or complete darkness. This ensures that your property remains protected around the clock, without sacrificing visibility or clarity.
Specifications
| Camera | |
|---|---|
| Imaging Device | 1/2.7", 8.0 Megapixel, Progressive Scan, CMOS |
| Effective Pixels | 8MP 3840(H)x2160(V) |
| Min. Illumination | Color 0.002Lux @F1.2(AGC ON); B/W 0 lux @ IR ON |
| Lens Type/Focal Length | Motorized 2.8-12mm |
| Max Aperture Ratio | F1.6 |
| Angular Field of View | Horizontal: 65°, Vertical: 91°, Diagonal: 120° |
| IR LED | 4 |
| Red/Blue Light | 2 (1 Red, 1 Blue) |
| IR Distance | 50m |
| Wide Dynamic Range | DWDR |
| Image Setting | Day/Night Auto Switch |
| White Balance | Auto/Manual |
| BLC | On/Off |
| AGC | Auto/Manual |
| Shutter Speed | 1/5s to 1/20000s |
| Image | |
| Video Compression | H.265+/H.264+/H.265/H.264 |
| Audio Compression | G.711a |
| Resolution | Mainstream: 8MP (3840x2160) @25fps Substream: 720P (1280x720) @25fps Mobilestream: VGA (640x480) @25fps |
| Video Quality Adjustment | 256Kbps - 16Mbps |
| Bitrate Control | CBR/VBR |
| Interfaces | |
| Network | RJ45 (10/100 Base-T) |
| Audio | Built-in Microphone and Speaker |
| Local Storage | Micro SD, up to 256GB |
| Network Storage | NAS (CIFS/SMB), FTP |
| Alarm | n/a |
| AI/AD | |
| Smart Motion Detection | Pedestrian, Vehicle, Perimeter Intrusion, Line Crossing |
| License Plate Recognition | Yes |
| Facial Recognition | Yes |
| Additional AI | Cross Counting, Stationary Object Detection, Heat Map, Crowd Density, Queue Depth, Rare Sound Detection |
| Active Deterrence | Siren, Red/Blue Strobe, Custom Voice |
| PTZ | |
| Pan Range | 0° ~ 355° |
| Pan Speed | Configurable 0.6° to 54°/s |
| Tilt Range | 0° ~ 90° |
| Tilt Speed | Configurable 0.6° to 54°/s |
| Preset | 255 |
| Preset Speed | Max 60°/sec |
| Tour | n/a |
| Patrol Scan | n/a |
| Pattern Scan | n/a |
| Functions | |
| Remote Monitoring | Web Browser, Client VMS, Mobile App |
| Mobile App | XVM |
| Network Protocol | IPv4, IPv6, TCP, UDP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, HTTPS, FTP, CIFS, SMB, UPnP, SNMP, |
| Interface Protocol | ONVIF (Profile S/G/T) |
| RS-485 Interface | n/a |
| Security | IP Address Filter, Complex Password, Authenticated User |
| General | |
| Power Supply | DC12V/POE, 14W Max. |
| PoE | Yes, 802.3af |
| Ingress Protection | IP66 |
| Dimensions (mm) | 100 x 238mm |
| Working Environment | Temperature: -20°C~ +60° (-4°F ~ 140°F) Humidity: Less than 90% RH |
| NDAA and FCC-Compliant | Yes |
Product Videos
Custom Field
Style PTZ
Resolution 8MP
Night Vision Infrared Black/White
Active Deterrence Yes
Audio Yes
Facial Recognition Yes
LPR Yes
Advanced AI Yes
FPS 25
Lens Motorized Varifocal
WDR DWDR
