Product Description
This sophisticated NVR offers powerful surveillance capabilities combined with next generation intelligent analytics. The X-Series NVR line uses advanced algorithms to detect and track people, vehicles, and other objects of interest, providing detailed information about their movement and activities. This makes it ideal for use in high-security environments such as airports, government facilities, and large corporations. The AI functions can also provide retail businesses a wealth of information to better learn consumer behavior and patterns. All of this combined with ultra high definition, real-time 4K recording on every channel. Don't be fooled by lower spec models. Smart, powerful, and affordable. This is the real deal. This is the X-Series.Specifications
| Video | |
|---|---|
| Camera Inputs | 64 |
| Camera Input Resolution | 12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1.0MP(720P) |
| Incoming Bandwdith | 640 Mbps |
| Outgoing Bandwidth | 640 Mbps |
| Output | 3 x HDMI (7680*4320/EDID, 3840*2160, 2560*1440, 1920*1080, 1440*900, 1280*1024, 1280*720, 1024*768) A-Sync Out 1 x HDMI (1920*1080/EDID, 1440*900, 1280*1024, 1280*720, 1024*768) A-Sync Out *If the HDMI 1 is set to 8K, HDMI 2 will be disabled, HDMI 3/4 limited to 1080P |
| Compression | H.265+, H.265, H.264+, H.264 |
| Streams | 3 - Mainstream, Substream, Mobile Stream |
| Audio | |
| Network Input | 64 Channels |
| Local Input | RCA x 1 |
| Local Output | RCA x 1, HDMI |
| Compression | G.711a, G.711u |
| Record | |
| Resolution | 12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP (960P), 1.0MP(720P) |
| Max Channel FPS | 60 FPS (camera dependent) |
| Max Channels at 4K@30FPS | 64-ch |
| Playback | |
| Simultaneous Playback | 16-ch |
| Search | Time Slice / Time / Event / Tag Search / Smart Search / Al |
| Function | Play, Pause, FF/FB (2/4/8/16x), Slow Forward (1/2, 1/4, 1/8, 1/16x), Single Frame Step |
| Frame Rate | 12MP: 60FPS, 4K: 240 FPS, 4MP: 480FPS, 2MP: 960FPS |
| Alarm | |
| Mode | Manual, Sensor, Motion, Exception, Al Events |
| Input | 16 Physical Inputs, Supports IP Camera Alarm Input |
| Output | 4 Physical Output, Supports IP Camera Alarm Output |
| Action | Record, Message, Push Notification, Email, FTP Image/Video upload, Cloud Image/Video upload, Voice Alert |
| Functions | |
| License Plate Recognition | Yes |
| Facial Recognition | Yes |
| Additional Al | Pedestrian, Vehicle, Perimeter Intrusion, Line Crossing, Cross Counting, Heat Map, Crowd Density, Queue Depth, Rare Sound, Abandoned/Missing Object, Video Tampering |
| Active Deterrence Support | Yes |
| Fisheye Dewarp | Yes (Dewarp also available using the X-VMS software) |
| Cloud Storage | Google Drive / Dropbox |
| Voice Assist | Amazon Alexa/Echo, Google Chromecast |
| Regions of Interest (ROI) | Yes |
| Other | Live Stream to Youtube.com |
| Mobile Device | |
| OS | Android, iOS |
| App | XMV |
| P2P Easy Setup | Yes |
| Primary Storage | |
| HDD Interface | SATA x 8 (up to 20 TB drives) |
| E-SATA | Yes |
| Network Storage | NAS (NFS, SMB/CIFS) |
| Disk Groups | Yes, RAID0/1/5/6/10 |
| Backup | |
| Local Backup | USB Flash, USB HDD |
| Network Backup | FTP, Cloud, NAS |
| Connections | |
| USB | 1 x USB 2.0 (front), 2 x USB 3.0 (rear) |
| RS485 | Yes |
| Ethernet | 2 x RJ-45 10/100/1000 Base-T |
| PoE | |
| PoE Ports | n/a |
| Standards | n/a |
| Output Power | n/a |
| General | |
| Power Supply | ATX 250W |
| Power Consumption | 8 W (without HDD) |
| Dimensions (mm) | 440 x 460 x 89 |
| Working Environment | Temperature: -10°C~ +50° (14°F ~ 122°F) Humidity: Less than 90% RH |
| NDAA-Compliant | Yes |
Product Videos
Custom Field
IP Channels 64
Record Resolution 12MP
HDD Bays 8
Max Internal Storage 100+ TB
Advanced AI Yes
HDMI Outputs 4
Network Interfaces 2
PoE Ports 0
