Product Description
Introducing the X-Series XP-DB01 Doorbell Camera.
The X-Series XP-DB01 Video Doorbell outperforms Ring and Blink with ZERO monthly fees. All video is stored locally on an installed MicroSD card, no cloud storage fees. Additionally, this unit can connect to any X-Series NVR or XVR for local recordings. Integrate your existing X-Series home security system with the new video doorbell!
- 1/2.7" 5.0 Megapixel, Progressive Scan, CMOS Sensor
- 5MP (1944 x 2592) @20FPS Encoding
- H.265/H.264 Video Compression
- Dual Band 2.4Ghz or 5Ghz Wifi
- PoE or 16-24V AC/DC Powered
- Person, Loitering, and Package Drop-Off/Pick-up Detection
- Full Head-to-Toe View
- SD Card Storage (up to 512GB)
- NVR Connectivity to X-Series NVR/XVR Models
- True 120db Wide Dynamic Range
- Dual-Stream Recording
- Infrared Night-Vision
- DDNS
- ONVIF Compatible
- IP65 Waterproof Rating
- NDAA and FCC Compliant
Specifications
| Camera | |
|---|---|
| Imaging Device | 1/2.7" 5MP Progressive Scan CMOS |
| Effective Pixels | 5MP (2592 × 1944) |
| Minimum Illumination | 0 Lux (IR On) |
| Lens | Fixed Lens, 2.1mm (M8) |
| Maximum Aperture | F2.0 |
| Field of View | Horizontal: 96° / Vertical: 132° / Diagonal: 163° |
| Minimum Object Distance | 0.5 m |
| IR Illumination | 1 IR LED (Up to 3 m) |
| Wide Dynamic Range | True WDR |
| Day / Night | IR Cut Filter (Auto / Schedule) |
| White Balance | Auto / Manual |
| BLC / HLC | Yes |
| Electronic Shutter | 1/5 ~ 1/20,000 sec |
| Digital Noise Reduction | 3D DNR |
| Image & Video | |
| Video Compression | H.265 / H.264 |
| Audio Compression | G.711a / G.711u |
| Resolution |
Main Stream: 5MP (2592 × 1944, 2400 × 1800) @ 20fps Sub Stream: 1MP (1280 × 960) @ 20fps |
| Video Bitrate | 256 Kbps – 6 Mbps |
| Bitrate Control | CBR / VBR |
| Interfaces | |
| Network | RJ45 (10/100 Mbps), Dual-Band Wi-Fi (2.4 / 5 GHz) |
| Audio | Built-in Microphone |
| Local Storage | MicroSD Card (Up to 512 GB) |
| Network Storage | X-Series IP NVR / XVR |
| Reset Button | Yes |
| AI & Active Deterrence | |
| Smart Motion Detection | Human Detection |
| Additional AI Features | Package Drop-Off, Package Pick-Up, Loitering Detection |
| Active Deterrence | Siren & Flashing Lights |
| Face Recognition | No |
| License Plate Recognition | No |
| System Functions | |
| Remote Monitoring | Web Browser, VMS Client, Mobile App |
| Mobile App | XVM Plus |
| Network Protocols | IPv4, TCP, UDP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, HTTPS, UPnP |
| ONVIF | Profile S / G / T |
| ANR | Yes |
| Security | Password Protection, Authenticated Users |
| General | |
| Power Supply | PoE or AC/DC 16–24V |
| Power Consumption | Max 9.84 W |
| PoE Standard | IEEE 802.3af |
| Ingress Protection | IP65 |
| Dimensions | 146 × 46 × 30 mm |
| Operating Environment | -25°C to +55°C (-13°F to 131°F), <90% RH |
| Weight | 115 g |
| Housing Material | Plastic |
| Compliance | NDAA & FCC Compliant |
Product Videos
Custom Field
Style Specialty
Resolution 5MP
Night Vision Infrared Black/White
Active Deterrence No
Audio Yes
Facial Recognition Yes
LPR Yes
Advanced AI Yes
FPS 30
Lens 2.8mm
WDR True 120dB
