Product Description
Introducing the X-Series 33x PTZ Camera with Auto Tracking and AI, designed to elevate your surveillance experience to a whole new level.Featuring a powerful 33x optical zoom lens and 5MP high resolution image sensor, this PTZ camera provides exceptional image quality, enabling you to capture crystal-clear footage even from a distance. Whether you're monitoring a large outdoor area or an indoor space, our camera delivers unparalleled detail and clarity, ensuring that you don't miss a thing.
With advanced auto-tracking capabilities, this camera automatically follows people or vehicles within its field of view, providing you with a seamless and uninterrupted surveillance experience. You can trust our camera to detect and track intruders and vehicles, giving you peace of mind that your property is always under watchful eyes.
Our PTZ Camera also comes equipped with AI technology, which takes your surveillance to the next level. With AI-powered features such as facial recognition and object detection, you can customize your camera's settings to suit your specific needs. The camera can even send real-time alerts to your phone or computer when it detects any suspicious activity, so you can act quickly and prevent any potential threats.
Additionally, the camera’s infrared night vision technology and low lux sensor allows for clear and detailed monitoring, even in low-light or complete darkness. This ensures that your property remains protected around the clock, without sacrificing visibility or clarity.
*Wall Mount Included
Specifications
| Camera | |
|---|---|
| Imaging Device | 1/2.7", 5.0 Megapixel, Progressive Scan, CMOS |
| Effective Pixels | 5MP 2592(H)x1944(V) |
| Min. Illumination | Color 0.003Lux @F1.6(AGC ON); B/W 0 lux @ IR ON |
| Lens Type/Focal Length | 4.3 - 142mm, 33x Optical Zoom< |
| Max Aperture Ratio | F1.6 |
| Angular Field of View | Horizontal: 55°-2.3°, Vertical: 42°-1.7°, Diagonal: 68°-3° |
| IR LED | 1 |
| Red/Blue Light | n/a |
| IR Distance | 150m |
| Wide Dynamic Range | DWDR |
| Image Setting | Day/Night Auto Switch |
| White Balance | Auto/Manual |
| BLC | On/Off |
| AGC | Auto/Manual |
| Shutter Speed | 1/5s to 1/20000s |
| Image | |
| Video Compression | H.265/H.264 |
| Audio Compression | G.711a |
| Resolution | Mainstream: 5MP (2592x1944) @30fps Substream: 720P (1280x720) @30fps Mobilestream: VGA (640x480) @30fps |
| Video Quality Adjustment | 256Kbps - 8Mbps |
| Bitrate Control | CBR/VBR |
| Interfaces | |
| Network | RJ45 (10/100 Base-T) |
| Audio | 1 Input / 1 Output |
| Local Storage | n/a |
| Network Storage | NAS (CIFS/SMB), FTP |
| Alarm | 1 Input / 1 Output |
| AI/AD | |
| Smart Motion Detection | Pedestrian, Vehicle, Perimeter Intrusion, Line Crossing |
| License Plate Recognition | No |
| Facial Recognition | Yes |
| Additional AI | Cross Counting, Stationary Object Detection, Heat Map |
| Active Deterrence | n/a |
| PTZ | |
| Pan Range | 360° |
| Pan Speed | Configurable 0.6° to 200°/s |
| Tilt Range | -10° ~ 90° (auto flip) |
| Tilt Speed | Configurable 0.6° to 90°/s |
| Preset | 255 |
| Preset Speed | Max 200°/sec Pan, 100°/sec Tilt |
| Tour | Yes |
| Patrol Scan | 1 |
| Pattern Scan | 4 |
| Functions | |
| Remote Monitoring | Web Browser, Client VMS, Mobile App |
| Mobile App | XVM |
| Network Protocol | IPv4, IPv6, TCP, UDP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, HTTPS, FTP, CIFS, SMB, UPnP, SNMP, |
| Interface Protocol | ONVIF (Profile S/G/T) |
| RS-485 Interface | Control by Joystick Controller (PTZ function only) |
| Security | IP Address Filter, Complex Password, Authenticated User |
| General | |
| Power Supply | DC12V/POE+, max 25.6W |
| PoE | Yes, 802.3at |
| Ingress Protection | IP66 |
| Dimensions (mm) | 206 x 397mm |
| Working Environment | Temperature: -30°C~ +60° (-22°F ~ 140°F) Humidity: Less than 90% RH |
| NDAA and FCC-Compliant | Yes |
Product Videos
Custom Field
Style PTZ
Resolution 5MP
Night Vision Infrared Black/White
Active Deterrence No
Audio No
Facial Recognition Yes
LPR No
Advanced AI Yes
FPS 30
Lens Zoom
WDR DWDR
