    G4 X-Series

    $2,813.00
    SKU:
    X-NVR-256-AI
    Adding to cart… category.add_cart_announcement

    Product Description

    This sophisticated 256 channel NVR offers powerful surveillance capabilities combined with next generation intelligent analytics. The X-Series NVR line uses advanced algorithms to detect and track people, vehicles, and other objects of interest, providing detailed information about their movement and activities. This makes it ideal for use in high-security environments such as airports, government facilities, and large corporations. The AI functions can also provide retail businesses a wealth of information to better learn consumer behavior and patterns. A whopping 1024 Mbps encoding bandwidth provides all of this in ultra high definition, real-time 4K recording on all 256 channels (using 4Mbps per camera). 64 channels can be viewed live simultaneously (at 720P substream resolution). 8K monitor support. Don't be fooled by lower spec models. Smart, powerful, and affordable. This is the real deal. This is the X-Series.

  • 256 Channels of IP Cameras, up to 4K@30FPS (4Mbps) on 256 Channels
  • Smart Motion Detection (Human, Vehicle, Perimeter, Line Crossing, etc.)
  • AI Analytics (Facial, Vehicle, License Plate, Cross Counting, Heat Map, Crowd Density, Queue Depth, Stranded Object, Missing Object, Gun Shot/Dog Bark/Baby Cry Detection)
  • 1024 Mbps Input Bandwidth
  • H.265+/H.265/H.264 Video Compression
  • Fisheye Dewarp
  • P2P Remote Access w/ Mobile App or Client Software via QR Code
  • Browser-based Remote Access
  • Four HDMI Video Display Outputs (HDMI 1@ 8K Resolution)
  • Two 10/100/1000 Network Interfaces
  • RAID, Hot-Swappable HDDs (Supports 16 HDD @ 20TB each)
  • Dropbox/Google Drive/FTP/Email Alarm Image/Video Support
  • RTMP Support for Streaming Live to Youtube
  • Amazon Alexa & Google Chromecast Support
  • DDNS Support
  • Network-Attached Storage and E-SATA for Unlimited Storage
  • NDAA Compliant
  • 3-Year Warranty

    • Specifications

    Video
    Camera Inputs 256
    Camera Input Resolution 12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1.0MP(720P)
    Incoming Bandwdith 1024 Mbps
    Outgoing Bandwidth 800 Mbps
    Output 3 x HDMI (7680*4320/EDID, 3840*2160, 2560*1440, 1920*1080, 1440*900, 1280*1024, 1280*720, 1024*768) A-Sync Out
    1 x HDMI (1920*1080/EDID, 1440*900, 1280*1024, 1280*720, 1024*768) A-Sync Out
    *If the HDMI 1 is set to 8K, HDMI 2 will be disabled, HDMI 3/4 limited to 1080P
    Compression H.265+, H.265, H.264+, H.264
    Streams 3 - Mainstream, Substream, Mobile Stream
    Audio
    Network Input 256 Channels
    Local Input RCA x 1
    Local Output RCA x 1, HDMI
    Compression G.711a, G.711u
    Record
    Resolution 12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP (960P), 1.0MP(720P)
    Max Channel FPS 60 FPS (camera dependent)
    Max Channels at 4K@30FPS 256-ch
    Playback
    Simultaneous Playback 16-ch
    Search Time Slice / Time / Event / Tag Search / Smart Search / Al
    Function Play, Pause, FF/FB (2/4/8/16x), Slow Forward (1/2, 1/4, 1/8, 1/16x), Single Frame Step
    Frame Rate 12MP: 60FPS, 4K: 240 FPS, 4MP: 480FPS, 2MP: 960FPS
    Alarm
    Mode Manual, Sensor, Motion, Exception, Al Events
    Input 16 Physical Inputs, Supports IP Camera Alarm Input
    Output 4 Physical Output, Supports IP Camera Alarm Output
    Action Record, Message, Push Notification, Email, FTP Image/Video upload, Cloud Image/Video upload, Voice Alert
    Functions
    License Plate Recognition Yes
    Facial Recognition Yes
    Additional Al Pedestrian, Vehicle, Perimeter Intrusion, Line Crossing, Cross Counting, Heat Map, Crowd Density, Queue Depth, Rare Sound, Abandoned/Missing Object, Video Tampering
    Active Deterrence Support Yes
    Fisheye Dewarp Yes (Dewarp also available using the X-VMS software)
    Cloud Storage Google Drive / Dropbox
    Voice Assist Amazon Alexa/Echo, Google Chromecast
    Regions of Interest (ROI) Yes
    Other Live Stream to Youtube.com
    Mobile Device
    OS Android, iOS
    App XMV
    P2P Easy Setup Yes
    Primary Storage
    HDD Interface SATA x 16 (up to 20 TB drives)
    E-SATA Yes
    Network Storage NAS (NFS, SMB/CIFS)
    Disk Groups Yes, RAID0/1/5/6/10
    Backup
    Local Backup USB Flash, USB HDD
    Network Backup FTP, Cloud, NAS
    Connections
    USB 1 x USB 2.0 (front), 2 x USB 3.0 (rear)
    RS485 Yes
    Ethernet 2 x RJ-45 10/100/1000 Base-T
    PoE
    PoE Ports n/a
    Standards n/a
    Output Power n/a
    General
    Power Supply ATX 250W
    Power Consumption 8 W (without HDD)
    Dimensions (mm) 440 x 460 x 89
    Working Environment Temperature: -10°C~ +50° (14°F ~ 122°F) Humidity: Less than 90% RH
    NDAA-Compliant Yes

    Product Videos

    Custom Field

    IP Channels 256
    Record Resolution 12MP
    HDD Bays 16
    Max Internal Storage 100+ TB
    Advanced AI Yes
    HDMI Outputs 4
    Network Interfaces 2
    PoE Ports 0
