| Video |
| Max Inputs |
24 (Combination of Analog and IP) |
| Analog Inputs |
16 BNC |
| Max IP Inputs |
24 |
| Analog Camera Input Resolution |
8MP (15FPS), 5MP (20FPS), 4MP and lower (30FPS) |
| IP Camera Input Resolution |
8MP/4MP/1080P/720P (30FPS) |
| Incoming Bandwdith |
184 Mbps |
| Outgoing Bandwidth |
184 Mbps |
| Output |
1 x HDMI (Max 3840x2160), 1 x VGA (Max 1920x1080), 1 x BNC (max 704x576) |
| Compression |
H.265, H.264 |
| Streams |
2 - Mainstream, Substream |
| Audio |
| Network Input |
24 Channels |
| Local Input |
RCA x 16 |
| Local Output |
RCA x 1, HDMI |
| Compression |
G.711a |
| Audio over Coax |
Yes (with X-Series HD Analog Cameras) |
| Record |
| Analog Resolution |
8MP (10FPS), 5MP (15FPS), 4MP (20FPS), 2MP and lower (30FPS) |
| IP Resolution |
8MP/4MP/1080P/720P (30FPS) |
| Max Channel FPS |
30 FPS (camera dependent) |
| Playback |
| Simultaneous Playback |
16-ch (Max 12-ch at 4K) |
| Search |
Time Slice / Time / Event / Tag Search / Smart Search / Al |
| Function |
Play, Pause, FF/FB (2/4/8/16x), Slow Forward (1/2, 1/4, 1/8, 1/16x), Single Frame Step |
| Frame Rate |
8MP: 120FPS, 5MP: 240 FPS, 4MP: 320FPS, 2MP: 480FPS |
| Alarm |
| Mode |
Manual, Sensor, Motion, Exception, Al Events |
| Input |
16 Physical Inputs, Supports IP Camera Alarm Input |
| Output |
1 Physical Output, Supports IP Camera Alarm Output |
| Action |
Record, Message, Push Notification, Email, FTP Image/Video upload, Cloud Image/Video upload, Voice Alert |
| AI |
| XVR-Provided (Any Analog Cam) |
PID - Perimeter Intrusion Detection
LCD - Line Crossing Detection
PD&VD - Pedestrian and Vehicle
FD - Facial Detection |
| IPC-Provided (X-Series IP Cams Only) |
LPR, Facial, Pedestrian, Vehicle, Perimeter Intrusion, Line Crossing, Cross Counting, Heat Map, Crowd Density, Queue Depth, Rare Sound, Abandoned/Missing Object, Video Tampering, Region Enter/Exit |
| Functions |
| Active Deterrence Support |
Yes (Camera Dependent) |
| Fisheye Dewarp |
No (Dewarp available on the X-VMS software or Mobile App) |
| Cloud Storage |
Google Drive / Dropbox |
| Voice Assist |
Amazon Alexa/Echo, Google Chromecast |
| Regions of Interest (ROI) |
Yes (Camera Dependent) |
| Protocols |
TCP / IP, IPv4, IPv6, PPPoE, DHCP, DNS, DDNS, HTTP, HTTPs, FTP, RTP, RTSP, NTP, SMTP, UDP, ONVIF, RTMP
|
| Other |
Live Stream to Youtube.com |
| Mobile Device/VMS |
| OS |
Android, iOS |
| App |
XMV |
| P2P Easy Setup |
Yes |
| PC Software |
X-VMS |
| Primary Storage |
| HDD Interface |
SATA x 2 (up to 16 TB drives) |
| E-SATA |
Yes |
| Network Storage |
NAS (NFS, SMB/CIFS) |
| Disk Groups |
No |
| Backup |
| Local Backup |
USB Flash, USB HDD |
| Network Backup |
VMS, Cloud, NAS |
| Connections |
| USB |
1 x USB 2.0 (front), 1 x USB 3.0 (rear) |
| RS485 |
Yes |
| Ethernet |
2 x RJ-45 10/100/1000 Base-T |
| PoE |
| PoE Ports |
None |
| Standards |
n/a |
| Output Power |
n/a |
| General |
| Power Supply |
12V, 5A |
| Power Consumption |
11 W (without HDD) |
| Dimensions (mm) |
380 x 340 x 50 |
| Working Environment |
Temperature: -10°C~ +50° (14°F ~ 122°F) Humidity: Less than 90% RH |
| NDAA-Compliant |
Yes |
