- 16 Channels of IP Cameras, up to 4K @ 30FPS All Channels
- Up to 12MP Recording Resolution (20FPS)
- Smart Motion Detection (Human, Vehicle, Perimeter, Line Crossing, etc.)
- AI Analytics (Facial, Vehicle, License Plate)
- 160 Mbps Input Bandwidth
- 16 Plug-n-Play PoE Ports
- H.265S/H.265+/H.265/H.264 Video Compression
- P2P Remote Access w/ Mobile App or Client Software via QR Code
- Browser-based Remote Access
- 4K HDMI Video Display Output
- 10/100/1000 Network Interface
- DDNS Support
- POS Support
- NDAA Compliant
-
Video Camera Inputs 16 CH IPC input Camera Input Resolution 12MP, 8MP, 6MP, 5MP, 3MP, 2MP(1080P), 1280x1024, 1.3MP(960P), 1.0MP(720P), 960H, D1, CIF Incoming Bandwidth 160 Mbps Outgoing Bandwidth 160 Mbps Output HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024/ 1024 × 768
VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768 (Independent Output if not using AI)Compression H.265S, H.265+, H.265, H.264 Streams 2 - Mainstream, Substream Audio Network Input 16 Channels Local Input RCA × 1 (for two-way audio) Local Output RCA x 1, HDMI Compression G.711a/u Record Resolution 12MP (20FPS)
8MP, 6MP, 5MP, 3MP, 2MP(1080P), 1280x1024, 1.3MP(960P), 1.0MP(720P), 960H, D1, CIF (30FPS)Max Channel FPS 30 FPS (camera dependent) Max Channels at 4K@30FPS 16-ch Playback Simultaneous Playback 16-ch Search Time Slice / Time / Event / Tag Search / Smart Search / Al Function Play, Pause, FF/FB Frame Rate 12MP: 20FPS, 8MP: 30FPS, 4MP: 60FPS, 2MP: 120FPS Alarm Mode Manual, Sensor, Motion, Exception, Al Events Input 8 Physical Inputs, Supports IP Camera Alarm Input Output 4 Physical Outputs, Supports IP Camera Alarm Output Action Record, Message, Push Notification, Email Functions Plate Recognition
Yes (If using Flux IP Cameras capable of LPR) Facial Recognition
Yes (If using Flux IP Cameras capable of Facial) Additional Al Pedestrian, Vehicle, Perimeter Intrusion, Line Crossing, Object abandoned/missing, Cross Counting, Heat Map, Crowd Density
Face Detection
Performance
(AI by IPC)16 CH Fisheye Dewarp Yes Cloud Storage No Voice Assist No Regions of Interest (ROI) Yes Other POS Support Mobile Device/VMS OS Android, iOS App SuperLive Plus P2P Easy Setup Yes PC Software Flux VMS Primary Storage HDD Interface SATA 3.0 x 2 (up to 12 TB drives) E-SATA No Network Storage No Disk Groups No Backup Local Backup USB Flash, USB HDD Network Backup VMS Connections USB 2 x USB 2.0, 1 x USB 3.0 RS485 Yes Ethernet 1 x RJ-45 10/100/1000M Base-T PoE PoE Ports 100M RJ45 × 16 Standards IEEE 802.3af/at Output Power ≤ 150W General Power Supply DC 48V/3.75A Power Consumption 20 W (without HDD) Dimensions (mm) 380 × 268× 45 ( W × D × H ) Working Environment Temperature: -10°C~ +50° (14°F ~ 122°F) Humidity: Less than 90% RH Certificate CE, FCC
